E4G 435-P AMGO 4 Post Parking/Service Lift – 3.5 Ton 1ph

E4G 435-P Specification:

• Lifting Capacity: 3.5Ton
• Lifting Height: 1872mm
• Lifting Time: 40 Seconds
• Gross Weight: 820kg
• Overall Length (inc ramps): 5257mm
• Overall Length (excl ramps):4400mm
• Overall Width: 2784mm
• Width between posts: 2438mm
• Overall Height: 2105mm
• The space from the outside of the platform to the outside of of the post is 447mm each side.

Main Features:

• 24V control system
• The power unit 1ph/3ph can be instaled on any post
• Ladder locks on all 4 posts
• The lift locks at 50cm and then every 10cm after that to 1720mm
• Variable height limit switch with warning “buzzer”
• One adjustable platform (just unbolt to slide) for narrow vehicles
• Skid proof diamond platform
• Detachable ramps which can be stored between the platforms
• Easily made portable using the optional caster kit
• Optional Peak J5H jacking beam, which slides between the platform
• Motor adds 250mm to the side (can reduce with motor bracket)

Additional Information:

• Not suitable for permanent outdoor use
• CE Approved
• Spares back up
• We can install or can be collected

Motors:

• E4G 81523001 – 1ph, 4HP, 220V, 18 amps, 11 litre.
• E4G 81523002 – 3ph, 3HP, 380V, 5.5 amps, 11 litre.

Optional Extras:

• Optional Oil Drip Tray x 4: Part number E4G 410039
• Caster Kit: Part number E4G 40801
• Jacking Beam: Part number E4G J5H

Manual:

 E4G 435-P Amgo 4 Post Parking Lift Manual
